Betterial offers 5 fluoropolymer backsheets, including 4 CPC-based models and 1 multilayer variant – BPF-807
BPF-801 and BPF-801C are opaque models differing in PET thickness, while BPF-803 and BPF-803M are transparent
All models provide high tensile strength, strong peel adhesion, and dimensional stability, with slight differences in specs for BPF-801C
Betterial, a Chinese supplier newly featured in the TaiyangNews Backsheets and Encapsulation Market Survey 2024/25, offers fluoropolymer-based backsheet products in 5 models: BPF-801, BPF-801C, BPF-803, BPF-803M, and BPF-807. The first 4 models were all launched in 2020. Introduced in 2022, BPF-807 is the latest and somewhat unique in its construction. This multilayer structured backsheet consists of a 288 µm PET core, stacked with a 10 µm PU (polyurethane) and a 20 µm barrier layer on the air side. In addition, it is further protected with a coating on both sides – 10 µm on the cell side and an outer coating of 5 µm.
Of the remaining 4, which are all based on the CPC configuration, BPF-801 and BPF-801C are opaque, while BPF-803 and BPF-803M are the transparent backsheet variants. The major difference between the opaque products for monofacial modules is the PET thickness. BPF-801 comes with a 288 µm core film and BPF-801C has a slightly thinner PET film of 275 µm, whereas the inner coating of 10 µm and the outer coating of 5 µm are the same for both products.
The key differentiation among the transparent variants is that the BPF-803M comes with a preprinted reflective mesh of 10 µm, which is offered with a color option between white and black. The remaining physical parameters of this backsheet are the same as those of the completely transparent BPF-803. Both products are built with a 295 µm core PET film coated with a 12 µm coating on both sides (see Betterial Lists POE-Based Encapsulants With UV Control Variants).
The company’s entire product range has nearly the same parameters, starting with tensile strengths exceeding 100 MPa, elongation values above 100% (MD) and 80% (TD), and dimension stability up to 0.6% at 150°C over 30 minutes. EVA peel strength is over 6 N/mm for all models. Performance varies slightly across models. While most products maintain a breakdown voltage of > 20 kV, BPF-801C is rated with a lower level of > 17 kV. Also, BPF-801C has a maximum system voltage of 1,000 V DC, while the rest of the products are 1,500 V DC models. Water vapor permeability for BPF-801C is ≤ 2.5 g/m²/d, slightly higher than the ≤ 2 g/m²/d for other variants.
For detailed information on Betterial offerings, please refer to the product description section of the report. The text is an excerpt from the latest TaiyangNews Market Survey on Backsheets & Encapsulation Materials 2024/25, which can be downloaded for free here.
